Fixed-width vs delimited files in a loader template

Before VICIdial can pull names and numbers out of a file, it has to know how the columns are separated. There are two common shapes a file can take, and a saved loader template can describe either one. Getting this right is the difference between clean Lead records and a list full of garbled data. The good news: once a template matches your layout, it works on any matching file regardless of the file type. For the wider context, see the lists and leads guide.

Delimited files

A delimited file uses a separator character between each piece of data. The most familiar is the comma in a CSV, but tabs and pipes are common too. The columns are wherever the separators fall, so a row can be wide or narrow and the loader still knows where each value starts and stops. When you upload a sample, the Lead loader inspects the file and works out the delimiter for plain text files automatically.

Fixed-width files

A fixed-width file has no separators at all. Instead, each field always occupies the same character positions in the row, padded with spaces so everything lines up like columns in a spreadsheet print-out. The phone might always sit in characters 1 through 10, the first name in 11 through 30, and so on. These files come out of older systems and mainframes, and they are unforgiving: one stray character shifts every field after it. If your provider hands you a file like this, ask them for a column-position spec so you can match each slice to the right field instead of guessing.

Whichever shape the file takes, the goal is the same: every value ends up in the field it belongs to so the dialer can act on it. A phone in the phone column, a state in the state column, and a Vendor lead code in its own slot if you track where each record came from. Get the layout wrong and a later Duplicate check can misfire because it is comparing the wrong columns, so it pays to confirm the mapping before you load the full batch.

flowchart LR
  A[Sample file] --> B{Separators present?}
  B -->|Yes| C[Delimited]
  B -->|No| D[Fixed-width]
  C --> E[Split on delimiter]
  D --> F[Cut by char position]
  E --> G[Map to list fields]
  F --> G

How a template describes the layout

Inside the template editor, each list column you want to fill gets an index value that points at a spot in the file row. The counting starts at 0, not 1, so the very first field in the row is index 0. You can reuse an index if two columns should pull from the same spot, and when fields share an index the editor shows them in the current-file-layout line separated by a pipe character. Any non-numeric junk you type into an index box is stripped out when you save.

The current-file-layout preview is a quote-and-comma view of how the template reads your file. Columns the template does not use show up as unused, which is a quick way to confirm you have not skipped anything important. Build the template against a small sample, under a hundred records, so the page loads in seconds and you can check the preview without waiting. There is a real gotcha here too: wait for the sample to finish loading before you touch any of the dropdowns. Click too early and the menus stay empty for good, and your only fix is to refresh and start the template over from scratch.
