How many concurrent channels does your carrier allow

A carrier's concurrent channel limit is the maximum number of calls it will carry for you at the same instant. That number is a hard ceiling on how many lines VICIdial can have up at once, so it directly limits how aggressively you can dial.

What a channel is

A Channel is one active call path. If you have 50 calls connected or ringing at the same moment, you're using 50 channels. Your Carrier sells you a cap on Concurrent calls — say 30, or 100, or 500 channels — and will not accept call number 31 (or 101, or 501) until one of the existing calls hangs up and frees a channel.

This is separate from how fast you place calls. The channel limit is about how many can be live at once; placement speed is a different limit. Both matter, but the channel cap is the one that bounds your peak.

It's easy to confuse channels with the number of leads or agents you have. They're unrelated. You could have 10,000 leads loaded and 20 agents working, but if the carrier gives you 40 channels, 40 is the most calls — connected, ringing, or in wrap-up on the line — that can exist across the whole campaign at any single instant.

How it limits your dial level

VICIdial's dial level — roughly, how many lines it opens per available agent — multiplies your agent count into live calls. With Predictive dialing at a dial level of 3 and 20 agents, the dialer may try to keep around 60 lines up. If your carrier only allows 40 channels, the dialer hits the ceiling: calls 41 and beyond get refused, and you'll see failed channels instead of connected calls.

flowchart TD
  A[Agents x dial level] --> B[Calls VICIdial wants to place]
  B --> C{Live channels under carrier cap?}
  C -->|Yes| D[Carrier accepts call]
  C -->|No, at cap| E[Carrier refuses call]
  E --> F[CHANUNAVAIL, wasted attempt]
  D --> G[Call connects to channel]
  G --> H[Channel frees on hangup]
  H --> C

Matching channels to agents

Size your channel allotment to the dial level you actually run, not just your agent count:

• Estimate peak lines as agents multiplied by your highest dial level, then add a little headroom.
• If the carrier's cap is below that, either buy more channels or lower your dial level so VICIdial stays under the limit.
• Spread load across more than one carrier if a single provider can't give you the channels you need.

Running into the cap doesn't just waste attempts — it skews your pacing math, because the dialer counts refused calls as failures and may adjust its behavior in ways you didn't intend. Keeping the channel limit comfortably above your peak demand keeps the dialer honest.

Where this fits

Channel limits are one of two carrier caps that shape your pacing — the other is calls per second. For the full carrier setup, see the VICIdial carrier integration guide. If one carrier can't carry your peak, spreading across multiple carriers with failover adds both capacity and resilience.
